dc drive panel

Name: dc drive panel
Brand: Riddhi Automation & Control
Price: 21000 INR
Availability: InStock

Price 21000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

dc drive panel Specification

Panel Type
Floor Mounted

Cooling System
Air Ventilation/Fan Cooled

Protection Level
IP54

Rated Current
1200A

Control System
Automatic / Manual Control

Cabinet Material
Mild Steel

Features
Short Circuit Protection, Overload Protection, User Friendly Interface, Customizable Design

Base Material
Mild Steel

Connectivity Type
Terminal Blocks, Cable Entry (Top/Bottom)

Components
MCB, MCCB, Fuses, Contactor, DC Drive, Indication Lamps, Control Relay

Operating Voltage
415V/220V

Protection Class
Class I

Current Rating
1200A

Rated Operation Voltage
415V AC

Cover Material
Other

Thickness
2mm

Way
Multi-way (as per design)

Rated Insulation Voltage
660V

Product Type
Other

Material
Mild Steel (MS)

Surface Finish
Powder Coated

Standard
IEC 60947 / IS standard

Surface Color
Other

Rated Voltage
415V AC

Frequency (MHz)
50 Hz

Maximum Output Current
1200A

Dimension (L*W*H)
1200mm x 1000mm x 400mm (approx.)

Application
Industrial Motor Speed Control

IP Rating
Ip54

Display Type
Digital (LED/ LCD)

Interlocking
Mechanical & Electrical Interlocks

Operating Mode
Forward/Reverse, Jog, Stop

Cable Entry
Top/Bottom

Panel Accessories
Cable Glands, Name Plates, Wiring Ducts, Control Wiring

Busbar Material
Electrolytic Copper

Compliance
RoHS Compliant

Humidity
Up to 95% non-condensing

Ambient Temperature
-10C to +50C

Panel Weight
Up to 150kg (Depending on Configuration)

Supported Drives
DC Motor Drives up to 450kW

Enclosure Type
Rittal/Custom Fabricated

Earthing Terminal
Provided

Mounting Type
Floor Standing

dc drive panel Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
10 Units Per Day

Delivery Time
1 Week

Main Domestic Market
All India

About dc drive panel

Jump on the new release DC Drive Panel designed for kingly industrial demands. Crafted with elite standards using uncommon electrolytic copper busbars, this floor-standing panel offers robust protection (IP54) and seamless operation, even in harsh environments. With dual cable entry, mechanical and electrical interlocks, and user-friendly digital displays, it boasts maximum savings on maintenance and downtime. Compatible with DC motor drives up to 450kW and fully RoHS compliant, this panel redefines high-current motor speed control with customizable, heavy-duty engineering and a regal finish.

Key Application Areas and Usage Highlights

The DC drive panel excels in diverse industrial and commercial sectors, providing superior motor speed control for manufacturing plants, processing units, and automation facilities. Designed for heavy and medium-duty usage, it is ideal for operations requiring precision, reliability, and flexibility in motor control. This elite drive solution is commonly implemented in assembly lines, rolling mills, paper mills, and textile industries where efficient, safe, and durable performance matters most.

Payment Terms, Certifications & Market Presence

We support a range of payment terms including advance, letter of credit, and exchange options to facilitate smooth business transactions. Our panels are delivered with certified RoHS compliance and meet IEC 60947/IS standards, ensuring trusted quality. Supply is available across India, with freight and logistics support for prompt delivery to key industrial hubs. We proudly serve the main domestic market, offering installation and after-sales service for all supplied panels.

FAQ's of dc drive panel:

Q: How does the DC drive panel ensure the safety of connected equipment?

A: The DC drive panel is engineered with short circuit and overload protection, both mechanical and electrical interlocks, and earthing terminals. It complies with Class I protection and offers IP54 ingress protection, making it reliable and safe for all industrial environments.

Q: What types of applications benefit most from this DC drive panel?

A: Industries reliant on motor speed control such as manufacturing, textile, processing plants, and rolling mills gain substantial benefits from this panel, thanks to its elite handling of DC motor drives up to 450kW and its robust, customizable design.

Q: Where can the DC drive panel be installed, and how is it mounted?

A: The panel is floor-mounted for stable operation in industrial settings. Featuring cable entry options from both the top and bottom, it can be installed flexibly in various facility layouts as per design requirements.

Q: What is the process for ordering and supply of the panel?

A: After selecting the required configuration, clients can place orders with flexible payment terms. We manage expedited supply and handle freight logistics, ensuring timely and safe delivery anywhere in India. Exchange and installation services are also available.

Q: What certifications and industry standards does your DC drive panel meet?

A: Our DC drive panel is RoHS compliant and manufactured according to IEC 60947 and relevant IS standards to ensure maximum quality and safety for industrial operations.
